300M / Min Wire Annealing Machine Apple Green 3.5M Furnace Length

Name: 300M Min Wire Annealing Machine Apple Green 35M Furnace Length
Brand: FUCHUAN
Price: 20000 USD

China 300M / Min Wire Annealing Machine Apple Green 3.5M Furnace Length wholesale

Brand Name : FUCHUAN

Model Number : FC-T12

Certification : ISO9001 2008

Place of Origin : CHINA

MOQ : 1SET

Price : USD20000

Payment Terms : T/T, L/C

Delivery Time : 8weeks

Packaging Details : simply water proof packing

Supply Ability : 500 set one year

fit for wire : 0.08-0.25mm or 0.15-0.64

number of inlet wire : 12pcs

pay off bobbin : diameter 300mm

machine color : sky blue or apple green

annealing method : tube annealing

max speed : 300m/min

pay off method : brush pay off

Contact Now

300M / Min Wire Annealing Machine Apple Green 3.5M Furnace Length

FC-T12 normal wire high speed annealing machine

Characteristics:

Easy to operate, good annealing heat preservation, save electricity, achieve industry-leading level.

Specification:

Equipment models	FC-T12
Twisting usage	It is mainly applied to the annealing of ultra-fine round copper wire and alloy wire.
Single wire dia(mm)	φ0.08-φ0.25 or φ0.15-φ0.64mm
Max numbers of inlet wire	12pcs
Linear speed	Max:300m/min
Pay off method	Brush pay off
Pay off bobbin model	φ300bobbin
Annealing furnace length	3.5m or 6m
Annealing method	Tube annealing
Annealing protection method	Water seal protection
Tinned method	Hot dip
Capstan control method	Inverter+ motor control or adopt stepless speed regulation motor
Equipment total power	53kw
Take up control	Take up is voltage regulator control the moment motor
Take up bobbin size	5inch,8inch bobbin or 5inch,8inch,10inch bobbin
Traverse control method	Stepless speed regulation motor+ turbine gear box control toothrow traverse
Installation size	14500L1500W2100H

Other Information

FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container
